Outdoor HD 1.3MP IR-CUT Onvif P2P CCTV IP Camera HW0048 manufacturer from China shenzhen wanscam co.,ltd

Outdoor HD 1.3MP IR-CUT Onvif P2P CCTV IP Camera

Price:	32.0 USD
Payment Terms:	T/T,L/C,WU,Paypal
Place of Origin:	Guangdong, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: HW0048

Packing: 20PCS/CTNS

Processor: Hi3518E

Production Capacity: 50000pcs/month

Delivery Date: Within 3-5 working days

P2P, H.264, 720P 128G TF Card
1. H.264, Megapixel. Hi 3518E. CMOS, DC 5V2A.
2. 11 LED, IR distance 10M. Lens 3.6 mm
3. Two-way audio, Indoor

P2P, H.264, 720P 128G TF Card
1. H.264, Megapixel. Hi 3518E. CMOS, DC 5V2A.
2. 11 LED, IR distance 10M. Lens 3.6 mm
3. Two-way audio, Indoor
4. Wi-Fi/802.11/b/g/n ,PC CMS to control multi-cameras. AP Function( easy to connect wifi).
5. Motion detection, email alert, FTP upload
6.Support Video Mask and Special Area Detection
7. Multi-language,Firefox, Safari, Google browser
8. Color: White+blue;
9.P2P, PNP: Plug&play, Support QR code scanning to view on Iphone and android Mobile
10.Support Max 128 G TF Card.
11.Support standard onvif protocol

Model No: HW0048
Ssystem	System Security	Supports there-level account, password, user authority management.
	OS	Embedded Linux OS
	Processor	Hi3518E
	P2P (Free)	No need to preset camera, Offer free P2P(WXH-000xxx-xxxxx), Plug&play, Support QR code scanning to view
	Onvif Protocol	Support ONVIF Protocol
	PC Browsers	Support 12 language remote surveillance, record, alarm, wifi setting etc.
	PC client	Support remote multi-devices monitor, record, alarm etc.
	Cell Phone View	Self R&D APP, Support Iphone,Android smart Phone
	TF Card Record	Support Max 128G TF card .Support the scheduled record,scheduled snapshot, and Intelligent record playback via browser
Lens	Lens Type	Lens Standard : 3.6 mm
Lens	IR-CUT	Build-in IR CUT, no color cast,auto switch when IR on
Video	Image Compression	H.264/MJPEG
	Sensor	1/4 Cmos 1MP
	Video Parameters	Brightness, Contrast,Saturation,Exposure,sharpness,VerticalAnd Horizontal can be adjusted
	Image Frame Rate	50Hz:25fps/60HZ:30fps (1280×720)
	First Stream	720P-(1280x720),(640x352)
	Second Stream	VGA-(640x352),(320x176)
Audio	Compression format	G.726/G.711(G.711 Default)
	Audio In	Built in Mic,also external supported
	Audio Out	Built in Speaker,also external supported
Night Vision	Lux	0 LUX
Night Vision	Night Visibility	11 Φ5 IR LEDs, Night visibility up to 10 meters
Pan/Tilt	Preset	Support 8 Preset Positions
	Rotation Angle	Pan:355°, Tilt:67°
	Rotation Speed	Pan: Speed Range 5-30°/ S; Tilt: Speed Range 5-50°/ S;
Alarm	Motion Detect	Support 4 Independent detection areas(Sensitivity can be adjustd 1-100)
Alarm	Alarm Action	Support Email Photo Alert,Snapshot and Record uploaded to TF Card
Network	Ethernet Interface	One 10/100Mbps RJ-45
	Supported Protocol	TCP/IP,HTTP,TCP,ICMP,UDP,ARP, IGMP,SMTP,FTP,DHCP,DNS,DDNS,NTP,UPNP,RTSP etc.
	Access Protocol	Onvif protocol
	IP Mode	Dynamic IP address, static IP address, PPPOE
	Online Visitor	Support Max 6 visitors at the same time (First Stream:3 visitors;Second Stream:3 visitors)
	Supported OS	Support Microsoft Win XP/Win7/Win8/ Mac OS.
	Browser	Support Internet Explorer ,FireFox,Google Browser, etc
	One Setting Function	Support APP One Setting Wifi Function
	Wireless Standard	WIFI, 802.11b/g/n
Others	OSD	Support the OSD name, date and time info superposition(Open/Off)
	Product Type	Cartoon Robot/ Indoor use
	Color	White With Blue
	Power	DC5V 2A
	Working Temperature	-10~50 °C
	Working Humidity	95% RH
	Size	Item:95115130mm(LWH); Packaging: 159149109mm(LWH)
	Weight	N.W.: 237g G.W.:475g (Note:Actual Weight Final)
	Accessories	Adaptor, CD,User manual,Bracket,Screws,Ethernet Cable
Certification	CE,FCC,RoHS
Warranty	Limited 2-Year Warranty
